Hibridni pretvarač SUN-6K-trofazni(LV)
O proizvodu
|
odel |
SUN-5K-SG04LP3-EU |
SUN-6K-SG04LP3-EU |
SUN-8K-SG04LP3-EU |
SUN-10K-SG04LP3-EU | SUN-12K-SG04LP3-EU |
|
Battery Input Data |
|||||
|
Battery Type |
Lead-acid or Lithium-ion |
||||
|
Battery Voltage Range (V) |
40~60 |
||||
|
Max. Charging Current (A) |
120 |
150 |
190 |
210 | 240 |
|
Max. Discharging Current (A) |
120 |
150 |
190 |
210 | 240 |
|
Charging Curve |
3 Stages / Equalization |
||||
|
External Temperature Sensor |
Yes |
||||
|
Charging Strategy for Li-Ion Battery |
Self-adaption to BMS |
||||
|
PV String Input Data |
|||||
|
Max. DC Input Power (W) |
6500 |
7800 |
10400 |
13000 | 15600 |
|
Rated PV Input Voltage (V) |
550(160~800) |
||||
|
Start-up Voltage (V) |
160 |
||||
|
MPPT Voltage Range (V) |
200-650 |
||||
|
Full Load DC Voltage Range (V) |
350-650 |
||||
|
PV Input Current (A) |
13+13 |
26+13 | |||
| Max. PV ISC (A) |
17+17 |
34+17 |
|||
|
No.of MPP Trackers |
2 |
||||
|
No.of Strings per MPP Tracker |
1+1 |
2+1 | |||
|
AC Output Data |
|||||
|
Rated AC Output Active Power (W) |
5000 |
6000 |
8000 |
10000 | 12000 |
|
Max AC Output Active Power (W) |
5500 |
6600 |
8800 |
11000 | 13200 |
|
AC Output Rated Current (A) |
7.6/7.2 |
9.1/8.7 |
12.1/11.6 |
15.2/14.5 | 18.2/17.4 |
|
Max AC Output Current (A) |
8.4/8 |
10/9.6 |
13.4/12.8 |
16.7/15.9 | 20/19.1 |
|
Max. AC Current (A) |
11.4/10.9 |
13.6/13 |
18.2/17.4 |
22.7/21.7 | 27.3/26.1 |
|
Max Output short circuit current(A) |
75 |
||||
|
Max. Continuous AC Passthrough (A) |
45 |
||||
|
|
2 time of rated power, 10 S |
||||
|
|
0.8 leading to 0.8 lagging |
||||
|
Output Frequency and Voltage |
50/60Hz;3L/N/PE 220/380Vac,230/400Vac |
||||
|
Grid Type |
Three Phase |
||||
|
|
<3% (of nominal power) |
||||
|
|
<0.5% In |
||||
|
Efficiency |
|
|
Max. Efficiency |
97.60% |
|
Euro Efficiency |
97.00% |
|
MPPT Efficiency |
99.90% |
|
Protection |
|
|
Integrated |
Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection |
|
Surge protection |
DC Type III / AC Type III |
|
Over Voltage Category |
DC Type II/AC Type III |
|
Certifications and Standards |
|
|
Grid Regulation |
VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1, G98, G99, C10-11, UNE217002, NBR16149/NBR16150 |
|
Safety EMC / Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
|
General Data |
|
|
Operating Temperature Range (?) |
-40~60?, >45? Derating |
|
Cooling |
Smart Cooling |
|
Noise (dB) |
?45 dB |
|
Communication with BMS |
RS485; CAN |
|
Weight (kg) |
33.6 |
|
Cabinet Size (WxHxD mm) |
422×702×281 (Excluding Connectors and Brackets) |
|
Protection Degree |
IP65 |
|
Installation Style |
Wall-mounted |
|
Warranty |
5 Years (10 Years Optional) |
